Model | ZL50-01BG | ||||||||
Working Voltage Range | DC: 6V-24V | ||||||||
Rating Power | 6V: 0-35W / 12V: 0-35W / 24V: 0-50W | ||||||||
Static Water Head | 0-10M | ||||||||
Static Flow Rate | 0-22L/min | ||||||||
Lifespan | Continuous operation≤24hrs, under normal working surrounding >20000hrs | ||||||||
Working Environment | Liquid: From weak acid to weak base, Non-submergible | ||||||||
Max Noise | Under normal working status, 1M distance over test instrument <45dB | ||||||||
Max Working Temperature | Under normal surroundings, fluid medium temperature≤100℃ (Aluminum alloy shell, PCB board outside) | ||||||||
Application | Car shower, Pipe pressurization, solar water heater, small fountain/aquarium, etc. | ||||||||
Size | IP Grade | Inlet | Outlet | Remarks | |||||
Length (mm) | Width (mm) | Height(mm) | OD(mm) | ID(mm) | OD(mm) | ID(mm) | Inlet and outlet with twist lock | ||
90 | 72 | 99 | IP67 | φ20.0 | φ12.5 | φ20.0 | φ6 | ||
Remark: It’s for reference only, the one based on the customer’s endorsement demands shall prevail!
